5 Port 10/100Mbps Fast Ethernet Switch Unmanaged Desktop Network Switch Plastic Housing Plug and Play External 5V Power Adapter TBC-S4005ES

Model Number : TBC-S4005E

Network Standards : IEEE802.3, IEEE802.3u, IEEE802.3x

Weight : ≤ 0.3kg

MOQ : 1

Packaging Details : Package:Carton Box

Packet Forwarding Rate : 0.744 Mpps

Flow Control : IEEE 802.3x Flow Control, Back Pressure

Dimensions : 81*52*22mm

Payment Terms : T/T

Fixed Port : 5 x 10/100Mbps adaptive RJ45 ports

Power Input : DC 5V/ 1A external power adapter

Certification : CE RoHS FCC,ISO9001

Exchange Method : Store-and-forward

Delivery Time : 5-8 working day

Transmission Distance : 100 meters

Auto MDI/MDIX : support

Brand Name : TiNCAM

Product Type : 5- port 10/100Mbps Ethernet switch

Temperature : Operating Temperature:-10～+55°C;Storage Temperature:-40～+75°C

Work Mode : Full-duplex/half-duplex auto-negotiation

Warranty : 1 year, lifetime maintenance

Place of Origin : China

Switching Capacity : 1Gbps

Supply Ability : 200,000 Pieces per Year

Transmission Medium : Category 5 and above twisted pair cable (Cat5e/Cat6/Cat6A)

Led Indicator Light : PWR: Power; indicator light 1-5: Network indicator lights

Installation Method : Desktop

Shell Material : Engineering plastic casing

Contact Now

Product Overview

The TBC-S4005E S is a 5-port 10/100Mbps auto-sensing Ethernet switch, compliant with IEEE 802.3, IEEE 802.3u, and IEEE 802.3x network standards. It features a plug-and-play design, allowing for quick and stable LAN setup without any configuration. The device provides five 10/100Mbps auto-sensing RJ45 ports, supporting Auto Negotiation and Auto MDI/MDIX functions, automatically identifying cable types and effectively reducing cabling complexity. The product features a compact engineering plastic housing and an external 5V DC power supply, making it suitable for home, small office, shop, surveillance systems, and SOHO network environments.

Key Features

• 5 x 10/100Mbps auto-sensing RJ45 Ethernet ports

• Compliant with IEEE 802.3, IEEE 802.3u, and IEEE 802.3x network standards

• Supports Auto Negotiation

• Supports Auto MDI/MDIX, eliminating the need to distinguish between straight-through and crossover cables.

• Store-and-forward exchange mechanism

• Supports IEEE 802.3x full-duplex flow control and half-duplex back pressure flow control

• Plug and play, no configuration required

• Desktop installation, suitable for a variety of network application scenarios.
